아두이노 나노 보드 CH340 / Arduino Nano CH340G Compatible / Header Assembly
판매가격 : 4,290원 (부가세 포함)
상품코드 :[11292]WAD-ZAS-MIZ-98548
제조사 :OEM
구매수량 : 일시품절된 상품입니다. (주문: 053-588-4080)
총 금액 :

  • 상품상세
  • 관련상품
  • 배송/교환/반품 안내
  • 상품리뷰


아두이노 나노 CH340입니다. 사용시 별도의 드라이버를 설치해야하며, 아래의 링크에서 다운로드 받을 수 있습니다.

(납땜되어있습니다.)


윈도우 운영체제 사용시 드라이버 설치 링크 : 바로가기


아두이노 나노 활용한 메이커 작품들




The Arduino Nano is a small, complete, and breadboard-friendly board based on the ATmega328. It has more or less the same functionality of the Arduino Duemilanove, but in a different package. It lacks only a DC power jack, and works with a Mini-B USB cable instead of a standard one. The version of the nano differs in that it doesn't use the standard FTDI chip to control the USB interface. Instead it uses the CH340. All this means for you is that you need to download drivers (supplied below). Once the drivers are installed, the nano will work in exactly the same way as those that use the FTDI chip, it's just cheaper to manufacture, and thus we're able to offer them at an excellent price.


Microcontroller: ATmega328
Operating Voltage (logic level): 5 V
Input Voltage (recommended): 7-12 V
Input Voltage (limits): 6-20 V
Digital I/O Pins: 14 (of which 6 provide PWM output)
Analogue Input Pins: 8
DC Current per I/O Pin: 40 mA
Flash Memory: 32 KB of which 2 KB used by bootloader
SRAM: 2 KB
EEPROM: 1 KB
Clock Speed: 16 MHz
Dimensions: 0.73" x 1.70"

Installation instructions and drivers available on our support forum here.
